Software Upgrade (Edge)
From Zenitel Wiki
|
This article is under construction! |
The software of Vingtor-Stentofon devices in an IC-EDGE System can be mass upgraded in two ways. Either:
- by using the VS-IMT tool
- from the Edge Controller
Contact mail:support.usa@zenitel.com to get the lates software version for Edge devices.
Contents
Upgrade using the VS-IMT tool
For a detailed procedure, see the VS-IMT Upgrade Stations
Upgrade from the Edge Controller
Prerequisites
- A TFTP Server must be available. A TFTP server can be downloaded from here: http://tftpd32.jounin.net/tftpd32_download.html.
- Unzip the software package and store the files in a folder on your PC.
- Check if your local firewall is not blocking incoming ping/ICMP (Turbine station is pinging TFTP Server during update process)
Upgrade procedure - Turbine devices
1. Start the TFTP server program and click Browse, and select the folder where the software files are located
2. Log on to the Turbine Station web interface. Default login credentials are admin and alphaadmin. Select Station Administration > Manual Upgrade
3. Enter the IP address of the TFTP server (I.e. the IP address of your PC)
4. Enter the image file prefixed by "boot": boot/vsft-4.11.3.0, and click Save settings. Wait a few seconds for the page to refresh, then press Upgrade. The station will now reboot. This process will upgrade the boot loader environment. For more details about this process, see Turbine bootloader upgrade
5. When the station is back online, enter the image file: vsft-4.11.3.0, and click Save settings. Wait a few seconds for the page to refresh, then press Upgrade. This process will upgrade the station firmware.
The upgrade procedure takes about 3 minutes. The process can be monitored by clicking the Log viewer tab in the TFTP server program.
|
If video is not working after having upgraded the Turbine Video Station TCIV-x to firmware version 4.11, see article TCIV - No video after upgrading to v. 4.11 |
